DMS-1500H Optical Property Test System
Suitable for small and medium size flat panel displays
Typical application scenarios
It is mainly used for the measurement of optical characteristics and ambient light contrast and other performance of small and medium-sized screens. The software controls the six-axis automatic rotation, and the black metal black box can realize the comprehensive evaluation of screen optics.
Main characteristics
1.Powerful test function
For each type of display, it can evaluate and analyze luminance uniformity, chromaticity uniformity, chromaticity coordinates, related color temperature, color gamut area, color gamut coverage, contrast, visual Angle, color bias, response time, flicker characteristics, GAMMA and other functions; the modular setting can be edited to handle multiple types of test items;
2.Simulate different kinds of ambient light
Optional hemispherical diffuse reflection lighting source, whole sphere diffuse reflection lighting source, integrating sphere directional light source for display reflectivity and ambient light contrast test evaluation, simulate the screen display characteristics under ambient light.
Technical Specifications
| Model | DMS-1500H |
| X-Y Axis Travel | Movement Range: Left/Right 200 mm, Front/Rear 180 mm; Resolution: 0.01 mm; Positioning Accuracy: 0.2 mm (Customizable for special requirements); Repeatability: ≤ 0.05 mm. |
| Z-Axis Travel | Distance between the Spectral Luminance Meter lens and the DUT (Device Under Test): 500 mm. |
| Vertical Rotation Axis of Sample Fixture | The sample stage rotates automatically around the vertical axis with a rotation range of 0–360° |
| Horizontal Rotation of Instrument Stage | The Spectral Color Luminance Meter rotates automatically around the product with a range of -90° to +90°. Rotation Accuracy: 0.1°, Repeat Accuracy: 0.05° |
| Sample Fixture Requirements | Equipped with a basic sample clamping device to facilitate the mounting of custom fixtures for user-supplied displays under test. Supported size: 3–15 inches; Load capacity: 20 kg |
